Description
Specification
| Brand | Merida |
|---|---|
| Frame | Carbon III – carbon main frame and rear triangle internal battery. Internal cable routing via Smart entry ports. Tapered head tube, 148 x 12mm axle standard. Max. tyre size 29″ x 2.6″ |
| Rear Shock | FOX Factory Float X2; 2 Pos Lever |
| Fork | FOX 38 Factory eMTB+; Air; 170mm travel; Tapered; 44mm fork offset; Max. tyre size 29″ x 2.6″ |
| Head Set | Acros ICR Merida integrated neck w/ Blocklock |
| Stem | Merida Expert eTR II; aluminium; 35mm diameter; 0 degree rise – Stem length: 40mm (all sizes). GoPro & Supernova mount point. |
| Handle Bars | Merida Expert eTR; 780mm wide; 20mm rise |
| Tape Grips | Merida Expert EC |
| Brakes | SRAM Code Ultimate Stealth 4 piston hydraulic disc brake caliper with SRAM HS2 220mm rotor |
| Brake Levers | SRAM Code Ultimate Stealth |
| Rear Derailleur | SRAM XX Eagle Transmission AXS wireless |
| Shift Levers | Limotech RM10 dropper post lever and SRAM AXS Pod Controller |
| Cassette | SRAM XX Eagle Transmission ; 10-52; 12 speed |
| Chainset | SRAM XX Eagle Transmission E-MTB for Steps; 34 tooth chainset with Shimano FC-EM900 165mm length crank all sizes; hollow with MRP 1x chainguide |
| Pedals | VP Components – VPE-527 |
| Wheels | DT Swiss Spline HXC1501 spline 30 boost; carbon; Tubeless ready (tubeless tape and valves included) |
| Front Tyre | Maxxis Assegai; 29″ x 2.5″; Kevlar bead; folding; TR EXO+ 3C MaxxGrip |
| Rear Tyre | Maxxis DHR II; 27.5″ x 2.6″; Kevlar bead, folding; 3C EXO+ TR |
| Saddle | Proxim W400 T2.0 with V-mount adapter; including Merida minitool |
| Seat Post | Merida Team TR II; 34.9mm diameter; in-line; all sizes 30-230mm seat post travel |
| Battery | 600Wh |
| Motor | Simplo Trend Power internal battery; 600Wh, Shimano Steps EP801; 85Nm |
| Discipline | MTB |
| Material | Carbon |
| Wheel size | 27.5″/29″ |
| Electric | Yes |
| Season | 2024 |
