SPECIFICATION
| Brand | Merida |
|---|---|
| Frame | Lite III – Hydroformed 6061 Double butted aluminium with intergrated battery. Internal cable routing via Smart entry ports. Tapered head tube, 148 x 12mm axle standard. Max. tyre size 27.5″ x 2.8″. |
| Rear Shock | FOX Float DPX2 Performance; platform |
| Fork | Marzocchi Z1 Ebike+; Air; 160mm travel; Tapered; 51mm fork offset. Max. tyre size: 29″ x 2.6″ |
| Head Set | Merida-8152 |
| Stem | Merida Expert eTRII; aluminium; 35mm diameter; 0 degree rise – Stem length: 40mm (all sizes). GoPro & Supernova mount point. |
| Handle Bars | Merida Expert eTR; 780mm wide; 20mm rise |
| Tape Grips | Merida Expert EC |
| Brakes | Shimano SLX; 4 piston hydraulic disc brake caliper with Shimano RT64; 203 mm rotor |
| Brake Levers | Shimano SLX |
| Rear Derailleur | Shimano XT RDM8100 Shadow+ 12 |
| Suspension | Full Suspension |
| Shift Levers | Shimano Deore SL-M6100 12 speed with Shimano SL -MT500-IL lever |
| Cassette | KMC e12T EPT |
| Chainset | Shimano CRE80-12-B; 34 tooth chainring with Shimano FCEM600; 165mm length crank |
| Pedals | Yes |
| Wheels | Merida Expert TR; 29mm inner rim width; Aluminium; Tubeless ready (tubeless tape and valves not included) |
| Front Tyre | Maxxis Assegai; 29″ x 2.5″; Kevlar bead; folding; TR EXO+ 3C MaxxGrip |
| Rear Tyre | Maxxis DHR II; 27.5″ x 2.6″; Kevlar bead, folding; 3C EXO+ TR |
| Saddle | Merida Expert CC; V-mount including Merida multitool |
| Seat Post | Merida Expert TR; 30.9mm diameter; in-line; Drop: 100mm (XS), 125mm (S), 150mm (M/L), 170mm (XL) |
| Battery | 630 Wh |
| Motor | Shimano E8036; 630Wh internal battery, Shimano Steps EP8; 85Nm |
| Material | Aluminium |
