Description
Specification
| Brand | Merida |
|---|---|
| Frame | CF5 IV – The highest quality fibres for minimum weight, aggressive Pro-Tour geometry and extensive aerodynamic profiling. Disc Cooler, BB86 BB standard, 142 x 12mm axle standard. Max tyre clearance 700 x 30c |
| Fork | Reacto CF5 IV Disc; full carbon, tapered steerer. Max tyre size: 700 x 30c. Disc cooler technology |
| Head Set | Merida Team SL; OP-203 neck |
| Stem | Team One-Piece Integrated; carbon. Length 90mm (XXS,XS), 100mm (S), 110mm (M) 120mm (L,XL) |
| Handle Bars | Team SL 1P Integrated; carbon; Width: 400mm (XXS,XS), 420mm (S,M,L), 440mm (XL) with Garmin + GoPro/Light Mount |
| Tape Grips | Merida Road Expert |
| Brakes | SRAM Force AXS hydraulic disc brake caliper with SRAM DB Paceline 160mm rotor |
| Brake Levers | SRAM Force AXS |
| Rear Derailleur | SRAM Force AXS |
| Shift Levers | SRAM Force AXS |
| Cassette | SRAM CS XG 1270 D1; 10-36 teeth; 12 speed |
| Chainset | SRAM Force AXS; 50-37 tooth chainset; Power Meter. Crank length: 165mm (XXS), 170mm (XS), 172.5mm (S,M), 175mm (L,XL) |
| Pedals | No |
| Wheels | Part of wheelset – Reynolds BL60 PRO, 21mm inner rim width; 60mm rim depth; carbon; Tubeless ready (tubeless tape and valves included) |
| Front Tyre | Continental Grand Prix 5000S TR; 700 x 28C; Kevlar bead, folding; tubeless ready |
| Rear Tyre | Continental Grand Prix 5000S TR; 700 x 28C; Kevlar bead, folding; tubeless ready |
| Saddle | Prologo Scratch M5 with V-mount adapter; including Merida minitool |
| Seat Post | Merida Team CW; Aero shape; 15mm lay back; Carbon with integrated rear light |
| Discipline | Road |
| Wheel size | 700c |
| Electric | No |
| Season | 2024 |
Reviews
There are no reviews yet.
