| Brand |
Whyte |
| Frame |
Uni-directional carbon mainframe and seatstays, Tapered Head tube, ISCG 2 Guide mounts, Internal cable routing, Shape.it Link V2 and 12,mm x 148mm Boost dropouts |
| Rear Shock |
Fox Float Factory, Evol LV, Adjustable Rebound and 3 Position Compression |
| Fork |
Fox Float 34 Factory 29″, 140mm Travel, 44mm Offset, Grip 2 Damper, Tapered Steerer, 110mm x 15mm Boost E-Thru Axle |
| Head Set |
FSA No.69/SRS 1-1/8″/1.5″ ACB – W/15mm top cover – side entry internal routing |
| Stem |
Whyte Trail Full CNC, 40mm Extension, 35 Barbore |
| Handle Bars |
Race Face NEXT R Carbon, 20mm Rise, 35mm Bar Bore, 800mm Wide |
| Tape Grips |
Whyte Lock-on Enduro Grip |
| Brakes |
SRAM Level Ultimate Stealth, 4 Piston, 200mmDisc / SRAM Level Ultimate Stealth, 4 Piston, 180mmDisc |
| Brake Levers |
SRAM Level Ultimate Stealth |
| Rear Derailleur |
SRAM XX SL T-Type AXS |
| Rear Hub |
DT SWISS XMC 180, Straight Pull, 6 bolt, 12 x 148mm, XD |
| Front Hub |
DT SWISS XMC 180, straight pull, 6 bolt, 15 x 110mm |
| Shift Levers |
SRAM AXS Pod, Right, MMX |
| Cassette |
SRAM XS 1297, T-Type, 10-52 |
| Chainset |
SRAM XX Isis Carbon, 165mm arms, XX Gen4 Direct Mount 32T, T-Type Light EMTB |
| Pedals |
Fibre Reinforced Composite Platform |
| Wheels |
DT SWISS XRC 1501 Spline |
| Front Tyre |
Good Year Escape Tubeless Ready Tan wall 29 x 2.4 800g front and rear |
| Rear Tyre |
Good Year Escape Tubeless Ready Tan wall 29 x 2.4 800g front and rear |
| Saddle |
Terra Aidon X1, 145mm, fibre reinforced nylon with Wingflex, Carbon 7x7mm rail |
| Seat Post |
KS Lev Ci, 30.9mm – 175mm drop, with Southpaw remote |
| Battery |
Bosch Compact Powertube 400Wh, integrated within the DT of the frame as the lowest point for stability and control |
| Motor |
Bosch Performance Line SX Drive Unit, 55Nm Maximum Torque, 600W Peak Power. Features 4 power settings including Tour+ that allows riders to focus on riding whilst being economic on power usage and e-MTB mode which automatically adjusts |
| Discipline |
MTB |
| Material |
Carbon |
| Wheel size |
29″ |
| Electric |
Yes |
| Season |
2024 |
