| Brand |
Whyte |
| Frame |
Uni-directional carbon mainframe and seatstays, Tapered Head tube, ISCG 2 Guide mounts, Internal cable routing, Shape.it Link V2 and 12,mm x 148mm Boost dropouts |
| Rear Shock |
Fox Float X Factory Series, EVOL, Lock Out, 210mm x 50mm |
| Fork |
Fox Float 34 Factory 29″, 140mm Travel, 44mm offset, Fit4 damper, Tapered steerer, 110m x 15mm Kabolt axle |
| Head Set |
FSA No.69/SRS 1-1/8″/1.5″ ACB – W/15mm top cover – side entry internal routing |
| Stem |
Whyte Trail Full CNC, 40mm Extension, 35 Barbore |
| Handle Bars |
Race Face Next R Carbon, 35mm barbore, 20mm rise, 800mm width |
| Tape Grips |
Whyte Lock-on Enduro Grip |
| Brakes |
Hope Tech4 V4, 4 piston, 200mm Floating Rotor / Hope Tech4 V4, 4 piston, 200mm Floating Rotor |
| Brake Levers |
Hope Tech 4 |
| Rear Derailleur |
SRAM XO T-Type AXS |
| Rear Hub |
Hope Pro 5, 6 bolt, 12mm x 148mm, XD, 32H |
| Front Hub |
Hope Pro 5, 6 bolt, 15mm x 110mm, 28H |
| Shift Levers |
SRAM AXS Pod, Right, MMX |
| Cassette |
SRAM XS 1295, T-Type, 10-52 |
| Chainset |
Hope E-Bike Cranks, 155mm length, Bosch mounting |
| Pedals |
Fibre Reinforced Composite Platform |
| Wheels |
Whyte Innegra Infussed Carbon Trail rims, 28H front, 32H rear |
| Front Tyre |
Good Year Newton MTF Trail, Tubeless Ready 29 x 2.5 Front, Good Year Newton MTR Enduro, Tubeless Ready 29 x 2.4 |
| Rear Tyre |
Good Year Newton MTF Trail, Tubeless Ready 29 x 2.5 Front, Good Year Newton MTR Enduro, Tubeless Ready 29 x 2.4 |
| Saddle |
Fizik Terra Aidon, 145mm wide, Wingflex, S-Alloy Mobius rail |
| Seat Post |
Whyte drop.it II Adjust, 30.9mm, M/L 140-170mm Travel, XL 170-200mm Travel, MMX Paddle Remote Lever |
| Battery |
Bosch Compact Powertube 400Wh, integrated within the DT of the frame as the lowest point for stability and control |
| Motor |
Bosch Performance Line SX Drive Unit, 55Nm Maximum Torque, 600W Peak Power. Features 4 power settings including Tour+ that allows riders to focus on riding whilst being economic on power usage and e-MTB mode which automatically adjusts |
| Discipline |
MTB |
| Material |
Carbon |
| Wheel size |
29″ |
| Electric |
Yes |
| Season |
2024 |
