| Brand |
Whyte |
| Frame |
Uni-directional carbon mainframe and seatstays, tapered head tube, ISCG 2 guide mounts, internal cable routing, Shape.it Link V2 and 12mm x 148mm Boost dropouts |
| Rear Shock |
RockShox Deluxe Select + RT, DebonAir, Fast Black coating, adjustable rebound and two position compression adjustment, custom tuned for Whyte |
| Fork |
RockShox Lyrik Select+, 150mm travel, DebonAir+, Charger 3.1 Damper, Fast Black coating, tapered steerer, 110 x 15mm Boost |
| Head Set |
FSA No. 69/56/SRS, 1-1/8in upper and 1.5in lower with sealed angular contact bearing (ACB) cartridge bearings, with side entry internal routing |
| Stem |
Whyte Trail full CNC, 32mm extension, 35mm bar bore |
| Handle Bars |
Whyte Custom 6061 alloy, 30mm rise, 35mm bar bore, 800mm wide |
| Tape Grips |
Whyte Enduro lock-on |
| Brakes |
SRAM Code Bronze Stealth, four piston hydraulic, 200mm diameter disc rotor |
| Brake Levers |
SRAM Code Bronze Stealth |
| Rear Derailleur |
SRAM S1000 T-Type AXS, 12 speed |
| Suspension |
Full Suspension |
| Rear Hub |
Alloy, light assist e-bike specific, double sealed cartridge bearings, 12mm x 148mm Boost spacing, 32 hole |
| Front Hub |
Alloy, double sealed cartridge bearings, 15mm x 110mm Boost spacing, 28 hole |
| Suspension Travel |
150mm |
| Shift Levers |
SRAM AXS Pod, right, MMX, 12 speed |
| Cassette |
SRAM XS 1270, T-Type, 10-52T, 12 speed |
| Chainset |
Whyte 155mm ISIS arms, SRAM Direct Mount 36T chainring, T-Type |
| Pedals |
Fibre reinforced composite platform |
| Wheels |
WTB ST Tough, 30mm internal width |
| Front Tyre |
Maxxis Minion DHF, EXO TR MaxxGrip 29in x 2.5in front; Maxxis Dissector, EXO+ TR MaxxTerra 29in x 2.4in, rear |
| Rear Tyre |
Maxxis Minion DHF, EXO TR MaxxGrip 29in x 2.5in front; Maxxis Dissector, EXO+ TR MaxxTerra 29in x 2.4in, rear |
| Saddle |
Whyte Custom |
| Seat Post |
TranzX +RAD 30.9mm, Adjustable, 125 drop (S), 150 drop (M), 170mm drop (L), 200mm drop (XL) |
| Battery |
Bosch Compact PowerTube 400Wh, integrated within the downtube of the frame at the lowest point for stability and control. Also comes with the external, removable 250Wh PowerMore range extender to deliver a combined 650Wh of battery capacity. |
| Motor |
Bosch Performance Line CX (Smart System) Drive Unit with 85Nm maximum torque, 600W of peak power and 250W of nominal power. Features four power mode settings including Tour+ and eMTB. |
| Discipline |
MTB |
| Material |
Carbon |
| Wheel size |
29″ |
| Electric |
Yes |
| Season |
2025 |
